Amada H-700 CNC Automatic Metal Bandsaw

MAIN FEATURES

Large Cutting Capacity for Heavy Sections
Cutting Capacity at 90°: 700 mm (W) × 400 mm (H)
Handles wide plates, solid blocks, and large structural profiles
Tip: Perfect for aerospace, power generation, and heavy fabrication industries.

CNC Automatic Operation
Full CNC control for programmable cutting cycles
Automatic material feeding and positioning
Ideal for batch and continuous production
Tip: CNC automation minimizes operator intervention and ensures consistent results.

Heavy-Duty Bandsaw Blade System
Blade Width: 54 mm (2")
Blade Thickness: 1.3 / 1.6 mm
Blade Length: 5890 mm (≈299")
Designed for high rigidity and straight cutting
Tip: Thicker blades provide stability when cutting hard alloys.

Variable Blade Speed Control
Blade Speed Range: 15 – 100 m/min (variable)
Optimized for different material hardness levels
Tip: Slower speeds reduce heat when cutting exotic metals.

Powerful Industrial Motor Setup
Saw Blade Motor: 3.7 kW
Hydraulic Pump Motor: 1.5 kW
Coolant Pump Motor: 0.06 kW
Ensures smooth cutting and reliable hydraulic operation
Tip: Balanced motor power improves cutting efficiency and blade longevity.

Hydraulic Blade Tension & Feed System
Automatic hydraulic blade tensioning
Controlled hydraulic down-feed for precision cutting
Tip: Correct blade tension prevents deviation and premature blade wear.

Blade Deviation Monitoring System
Detects blade twist beyond preset limits
Automatically stops the cutting process
Protects blade and material
Tip: Especially useful when cutting high-value materials.

Advanced Vise System
Full-stroke hydraulic vises
Variable clamping pressure
Front vise stroke: 500 mm
Improves remnant handling and positioning
Tip: Proper vise control enhances cut accuracy on large workpieces.

Hard-Metal Cutting Capability
Designed for tough and heat-resistant alloys
Maintains accuracy under heavy cutting loads
Tip: Ideal for aerospace and high-strength steel applications.

Integrated Chip Conveyor
Standard chip conveyor
Improves cleanliness and productivity
Tip: Continuous chip removal prevents blade clogging and overheating.

Rigid Industrial Construction
Heavy-duty welded steel frame
Built for vibration-free cutting
Tip: A rigid frame ensures superior straightness on long cuts.

COMMON QUESTIONS

700 mm (W) × 400 mm (H) at 90°.

Yes, it features full CNC automatic operation.

54 mm wide × 1.3/1.6 mm thick × 5890 mm long.

Carbon steel, stainless steel, titanium, Inconel, Hastelloy, and alloys.

Yes, variable blade speed from 15–100 m/min.

Yes, it automatically stops cutting if blade twist exceeds limits.

Yes, the chip conveyor is standard.

Hydraulic full-stroke vises with variable pressure.

500 mm.

Yes, blade tensioning is hydraulic.

Yes, it is designed for high-volume industrial use.

Approximately 3500 kg.

Yes, it is ideal for cutting hard aerospace alloys.

Very high accuracy due to CNC control and blade monitoring.

Manufacturers requiring high-precision cutting of large and hard metal materials.
