Large-Capacity Cutting Performance
90° Cutting Capacity: 750 mm (H) × 450 mm (W)
45° Cutting Capacity: 426 mm × 426 mm
Handles heavy beams, billets, pipes, and large structural profiles with ease.
Tip: Use lower blade speeds for thick alloy materials to extend blade life.
Heavy-Duty Industrial Blade System
Blade Size: 5790 mm (L) × 41 mm (W) × 1.3 mm (T)
Optimized for vibration-free cutting and long service life
Tip: Maintain correct hydraulic blade tension to ensure straight cuts on wide stock.
CNC Windows-Based Control System
User-friendly Windows CNC interface
Precise hydraulic flow control with stepping motor
Program multiple cutting lengths and quantities
Tip: Use CNC batch programs to minimize operator intervention during long production runs.
Variable Inverter-Controlled Blade Speed
Blade Speed Range: Approx. 15–150 m/min (50–492 ft/min)
Easily adjustable for mild steel, stainless steel, and alloy materials
Tip: Higher blade speeds improve productivity on softer materials.
High-Power Drive & Hydraulic System
Saw Motor: 10 HP (7.5 kW)
Hydraulic Pump Motor: 2 HP (1.5 kW)
Hydraulic blade tensioning for consistent cutting pressure
Tip: Stable hydraulic pressure ensures consistent surface finish on every cut.
Hydraulic Front & Rear Vise Clamping
Full hydraulic vise system
Secure material holding for heavy and large sections
Ideal for bundle and single-piece cutting
Tip: Proper vise alignment reduces blade drift and improves accuracy.
Shuttle-Type Indexing for Automation
Front Stroke: 300 mm (11.8")
Rear Stroke: 400 mm (15.7")
Enables precise material feeding for repeat cuts
Tip: Smart indexing minimizes remnant waste to as low as 15 mm.
Advanced Material Handling & Productivity Features
Automatic cutting cycle
Built-in chip conveyor
Smart remnant positioning
Designed for continuous, unattended operation
Tip: Clean chip conveyor regularly to prevent coolant contamination.
High-Capacity Coolant System
Cutting Fluid Tank: 230 liters
Ensures blade cooling during extended cutting cycles
Tip: Maintain coolant concentration to prevent blade overheating.
Robust Industrial Construction
Machine Weight: Approx. 4200 kg (9261 lbs)
Extremely stable cutting platform for large materials
Built for long-term heavy-duty use
Up to 750 mm × 450 mm.
Up to 426 mm × 426 mm.
Yes, it supports fully automatic CNC operation.
5790 mm length × 41 mm width × 1.3 mm thickness.
Approximately 15–150 m/min.
Windows-based CNC control.
Yes, hydraulic blade tensioning is standard.
10 HP (7.5 kW).
Hydraulic front and rear vises.
Shuttle-type vise system.
As low as 15 mm, plus part length.
Yes, chip conveyor is included for continuous operation.
230 liters.
Steel service centers, heavy fabrication, construction equipment, and structural steel plants.
Approximately 4200 kg (9261 lbs).
| Blade Length inches | 228" |
| Min/Max Blade Width | 2" to 2" |
| Machine Type | Metal |
| Machine Type | CNC Automatic Horizontal Metal Bandsaw |
| Cutting Capacity (90°) | 750 mm × 450 mm |
| Cutting Capacity (45°) | 426 mm × 426 mm |
| Blade Speed | 15–150 m/min (Inverter Controlled) |
| Control System | Windows CNC |
| Blade Tension | Hydraulic |
| Index Stroke (Front / Rear) | 300 mm / 400 mm |
| Minimum Remnant Length | 15 mm |
| Saw Motor Power | 10 HP (7.5 kW) |
| Hydraulic Motor Power | 2 HP (1.5 kW) |
| Power Supply | 220V, 3-Phase, 60 Hz |
| Coolant Tank Capacity | 230 liters |
| Machine Dimensions (W × L × H) | 2260 × 2257 × 2304 mm |
| Machine Weight | Approx. 4200 kg |
