Large Cutting Capacity for Versatile Applications
Round Capacity: Approx. 400–420 mm (16")
Rectangular Capacity: Approx. 415 × 415 mm (16.3" × 16.3")
Handles solids, tubes, bundles, and profiles
Tip: Perfect for medium-to-large section cutting in production environments.
Fully Automatic Hydraulic Operation
Complete automatic cutting cycle
Hydraulic control of blade feed, vise clamping, and tension
Tip: Automation improves productivity and ensures consistent cut quality.
Multi-Index Feed System
Automatic stroke length: Up to 4500 mm
Supports multi-index feeding (up to 9 strokes)
Tip: Ideal for long bar cutting without manual repositioning.
High-Performance Blade Drive Motor
Motor Power: 5.5 kW (approx. 7.5 HP)
Maintains steady torque under heavy cutting loads
Tip: Ensures stable cutting even on high-strength alloys.
Variable Blade Speed Control
Blade Speed Range: Approx. 15–90 m/min (50 Hz)
Optimized for different materials and profiles
Tip: Lower speeds improve blade life on harder metals.
Heavy-Duty Blade Specifications
Blade Length: 4570 mm
Blade Width: 34 mm (1.25")
Designed for straight, vibration-free cutting
Tip: Correct blade selection enhances surface finish.
Hydraulic Blade Tensioning System
Maintains optimal blade tension automatically
Reduces blade deflection and premature wear
Tip: Proper tension improves cutting accuracy.
Precision Hydraulic Vise Clamping
Strong vise clamping ensures material stability
Minimizes movement during cutting
Tip: Stable clamping leads to cleaner, burr-free cuts.
Integrated Coolant System
Continuous coolant flow to cutting zone
Controls heat buildup and extends blade life
Tip: Essential for continuous production cycles.
Automatic Chip Auger
Efficient chip removal during operation
Keeps the cutting area clean
Tip: Reduces downtime and maintenance interruptions.
Multi-Material Cutting Capability
Suitable for steel, aluminum, and high-strength alloys
Consistent performance across materials
Tip: One machine for diverse cutting requirements.
Rigid Industrial Frame Construction
Heavy-duty machine body
Minimizes vibration and structural flex
Tip: Rigid construction ensures long-term accuracy.
What type of bandsaw is the Amada HA-400?
Approximately 400–420 mm (16 inches).
What rectangular size can it cut?
Steel, aluminum, and high-strength alloy materials.
4570 mm length × 34 mm width.
Yes, it features variable blade speed control.
Approximately 15–90 m/min at 50 Hz.
Yes, it supports fully automatic cutting cycles.
It allows the machine to feed long materials in multiple strokes.
Up to 4500 mm.
Yes, it has a hydraulic blade tensioner.
Yes, an integrated coolant system is standard.
Via an automatic chip auger.
Yes, it is designed for industrial continuous operation.
Fabrication shops, steel service centers, and manufacturing plants.
| Blade Length inches | 180" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Cutting Capacity – Round | Approx. 400–420 mm (16") |
| Approx. 400–420 mm (16") | Approx. 415 × 415 mm |
| Blade Speed | Variable, approx. 15–90 m/min |
| Blade Motor Power | 5.5 kW (approx. 7.5 HP) |
| Feed System | Automatic Multi-Index (up to 9 strokes) |
| Automatic Stroke Length | Up to 4500 mm |
| Chip Removal | Automatic Chip Auger |
| Applications | Steel, Aluminum, High-Strength Alloys |
