Industrial Cutting Capacity
Round cutting capacity up to 10" (250mm)
Rectangular capacity approx. 10" × 10"
Suitable for steels, alloys, stainless, tool steels, solid bars & bundles (with optional clamps)
Automatic Operation for Productivity
Fully automatic cutting cycles
Auto-feed bar advancement with multi-stroke capability
Hydraulic vise clamping ensures stable cuts
Perfect for unattended or semi-unattended production
Durable 1" Wide Blade
Uses a 137" long × 1" wide blade
Optimized for straight, consistent cutting
Precision carbide blade guides maintain cutting accuracy
Variable Blade Speed
Adjustable blade speed for cutting different metals
Supports mild steel, alloy steel, tool steel & stainless
Ensures optimal blade life and smooth finish quality
Heavy-Duty Construction
Rigid saw head reduces vibration
Precision-machined bed ensures long-term alignment
Amada’s legendary durability ensures years of dependable service
User-Friendly Amada Control System
Simple operator panel
Adjustable material feed length
Rapid setup for production runs
Precise digital control over cutting parameters
It cuts 10-inch round and approximately 10" x 10" rectangular stock.
Yes, it offers full automatic cutting and feeding cycles.
A 137-inch long, 1-inch wide metal-cutting blade.
Yes—adjust blade type and speed for stainless and hard alloys.
Yes, front and rear hydraulic vises secure the material.
Yes, with optional bundle clamps.
Yes, it has variable blade speed for different metals.
It is designed specifically for high-volume industrial cutting.
Yes, it can automatically advance long bars in multiple strokes.
Steel service centers, fabrication shops, machine shops, automotive, aerospace, and OEM manufacturers.
Yes, it provides strong cutting performance with a smaller footprint.
Yes, the design allows quick blade access.
Most units come equipped with a chip conveyor system.
No, Amada machines are designed for easy daily maintenance.
Mild steel, tool steel, alloy steel, stainless steel, tubing, pipes, and structural profiles.
| Blade Length inches | 138" |
| Min/Max Blade Width | 1" to 1" |
| Machine Type | Metal |
| Round Capacity | 10" (250mm) |
| Rectangular Capacity | 254 mm x 304.8 mm |
| Stack cutting | 250 mm x 270 mm |
| Blade size | 3505 mm x 32 mm x 1.066 mm |
| Blade speed | 24 to 90 m/min ( 79 to 295 fpm) (stepless shift) |
| Motor | 3.7 kW (5 HP) |
| Hydraulic pump motor | 0.75 kW (1.0 HP) |
| Cutting fluid pump motor | 0.18 kW (0.24 HP) |
| Power source | 3-phase |
| Workload capacity | 1500 kg ( 3307 lbs ) |
| Machine weight | 1501 kg ( 3310 lbs ) |
| Overall dimensions | 1953 mm x 2370 mm x 1285 mm |
