Strong Cutting Capacity for Production Work
Round Capacity: 10" (250 mm)
Rectangular Capacity: 10.6" × 10" (269 × 254 mm)
Suitable for solid bars, pipes, and profiles
Tip: Ideal for medium-diameter stock requiring repeatable accuracy.
Fully Automatic Operation with PLC Control
PLC controller stores up to 99 cutting jobs
Automatic cutting cycles reduce manual intervention
Tip: Job memory is perfect for batch and repeat production.
Precision Split Front Vise System
Split vise design reduces burr formation
Improves cut finish and dimensional accuracy
Tip: Especially useful for downstream machining operations.
Stepless Variable Blade Speed
Blade Speed Range: 89–295 ft/min (24–90 m/min)
Optimized cutting for mild steel, alloy steel, and structural metals
Tip: Lower speeds extend blade life on hard materials.
Heavy-Duty Blade and Drive System
Blade Size: 11'6" × 1-1/4" × 0.042" (3505 × 32 × 1.066 mm)
Stable blade tracking for straight, clean cuts
Tip: Use premium blades to maximize cutting performance.
Powerful Industrial Motor
Motor Power: 3.7 kW / 5 HP
Consistent torque under heavy cutting loads
Tip: Maintains cut accuracy during continuous operation.
Hydraulic Blade Tensioning
Ensures consistent blade tension
Reduces blade fatigue and breakage
Tip: Proper tension improves surface finish and accuracy.
Blade Deviation Monitoring System
Detects blade twist or deviation
Automatically protects blade and workpiece
Tip: Prevents costly blade damage and scrap.
High Workload Capacity
Workload Capacity: Approx. 1,500 kg (3,307 lbs)
Supports heavy bundled or single stock
Tip: Ideal for steel service centers.
Integrated Chip Management
Powered chip conveyor removes chips efficiently
Coolant recycling for cleaner operation
Tip: Keeps the cutting area clean and productive.
Self-Diagnostics and Error Alerts
Built-in diagnostics for troubleshooting
Error indicators reduce downtime
Tip: Faster maintenance response improves uptime.
Rigid Industrial Construction
Heavy steel frame minimizes vibration
Long-term cutting accuracy
Tip: Stability directly improves blade life.
Steel, alloy steel, pipes, and structural profiles.
Yes, it features fully automatic operation with PLC control.
10 inches (250 mm).
3505 mm × 32 mm × 1.066 mm (11'6" × 1-1/4" × 0.042").
Yes, stepless variable speed from 24–90 m/min.
A 3.7 kW (5 HP) motor.
Yes, hydraulic tensioning is standard.
It minimizes burrs and improves cut quality.
Yes, up to 99 jobs can be stored in the PLC.
Yes, for improved safety and accuracy.
Yes, a powered chip conveyor is standard.
Approximately 1,500 kg (3,307 lbs).
Yes, with coolant recycling through the conveyor.
Yes, it is designed for high-duty industrial use.
Fabrication shops, steel service centers, and manufacturing plants.
| Blade Length inches | 138" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Cutting Capacity – Round | 10" (250 mm) |
| Cutting Capacity – Rectangle | 10.6" × 10" (269 × 254 mm) |
| Blade Thickness | 0.042" (1.066 mm) |
| Blade Speed | 24–90 m/min (Stepless) |
| Blade Motor Power | 3.7 kW / 5 HP |
| Control System | PLC Controller (99 jobs) |
| Workload Capacity | Approx. 1,500 kg |
| Chip Management | Powered Chip Conveyor |
| Machine Dimensions (W×D×H) | 1945 × 2366 × 1285 mm |
| Machine Weight | Approx. 1,500 kg |
