1. High Cutting Capacity (Up to 320 mm)
Round Capacity (90°): 320 mm
Flat Capacity (90°): 350 × 320 mm
Minimum Cutting Length: 70 mm
This wide cutting range allows the HBE 321A to handle solid bars, flats, tubes, and structural profiles efficiently.
2. Fully Automatic Operation
Automatic material feed system
Single stroke feed length: 650 mm (25.6")
Programmable cutting cycles
Repeatable precision for batch production
Ideal for production workshops requiring consistent and repeatable cutting performance.
3. Energy-Efficient Drive System
Saw Motor Power: 3.7 kW
Optimized power transmission
Reduced energy consumption compared to older hydraulic-only systems
Behringer’s efficient drive design ensures lower operational costs while maintaining high cutting performance.
4. Variable Blade Speed (Vario Control)
Adjustable cutting speed: 15 – 110 m/min
Stepless speed control
Suitable for carbon steel, alloy steel, stainless steel, and tool steels
Allows precise speed selection based on material hardness and cross-section.
5. Precision Saw Blade System
Blade Dimensions: 4440 × 34 × 1.1 mm
Blade Length (Inches): 175"
Blade Width: 1.25" (34 mm)
Blade Thickness: 0.042"
Compatible with high-performance bi-metal blades (M42/M51) for long blade life and consistent results.
6. Rigid Horizontal Frame Construction
Heavy-duty steel-welded frame
Low vibration design
Accurate straight-line cutting
Improved blade tracking stability
This ensures smooth operation even during continuous cutting cycles.
7. Hydraulic Clamping & Feed System
Hydraulic vice with adjustable pressure
Secure material positioning
Stable cutting performance
Prevents material movement and enhances dimensional accuracy.
8. Integrated Coolant System
Continuous blade lubrication
Reduced heat build-up
Extended blade life
Improved surface finish
9. Compact Industrial Footprint
Dimensions: Approx. 2500 × 2000 × 1900 mm
Weight: ~2000 kg
Perfect for workshops that need industrial performance without excessive floor space requirements.
10. Designed for Production Efficiency
Fast cycle times
Clean cut surfaces
Minimal post-processing
Easy blade replacement and maintenance access
The HBE 321A balances precision and productivity for metal processing operations.
Up to 320 mm for round materials.
Yes, it features automatic material feed and programmable cutting cycles.
4440 × 34 × 1.1 mm (175" length).
Yes, variable from 15 to 110 m/min.
3.7 kW saw drive motor.
Carbon steel, alloy steel, stainless steel, and structural materials.
70 mm.
650 mm per single stroke.
Yes, an integrated coolant system is standard.
Yes, ideal for small-to-medium batch production.
Approximately 2000 kg.
Yes, designed with energy-optimized drives.
Yes, up to 350 × 320 mm.
Bi-metal M42 or M51 blades.
For precision German engineering, automation, and reliable cutting performance.
| Blade Length inches | 175" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Cutting Capacity (Round 90°) | 320 mm |
| Cutting Capacity (Flat 90°) | 350 × 320 mm |
| Minimum Cutting Length | 70 mm |
| Feed Length (Single Stroke) | 650 mm |
| Blade Thickness | 1.1 mm (0.042") |
| Blade Speed | 15 – 110 m/min (Variable) |
| Drive Motor Power | 3.7 kW |
| Machine Weight | 1900 kg (4189 lbs) |
| Dimensions (L × W × H) | 2500 × 2000 × 1900 mm |
