260 mm Cutting Capacity (90°)
Round Capacity: 260 mm (10.2”)
Rectangular Capacity: 300 x 260 mm (11.8” x 10.2”)
Suitable for cutting solid bars, pipes, bundles, and structural sections
Provides excellent versatility for small to medium steel processing operations.
Automatic Operation with Hydraulic Feed
Fully automatic cutting cycle
Hydraulic material clamping system
Automatic blade feed control
Designed for repetitive batch cutting
Reduces operator workload and increases productivity.
High-Precision Twin Column Construction
Parallel down-feed system
Stable cutting frame
Reduced vibration during heavy cuts
Ensures straight and accurate cuts
The dual-column design improves blade life and enhances cutting consistency.
Optimized Saw Blade System
Blade Dimensions: 1.25" x 15’3" x .042"
Approximate Metric Size: 4640 x 32 x 1.1 mm
Blade Length: 182 inches
Blade Width: 1.25 inches (32 mm)
Designed for smooth tracking and high-performance metal cutting.
Variable Band Speed Control
Speed Range: 30 – 217 m/min
(Approx. 45 – 410 FPM depending on variant)
Stepless or variable adjustment
Ideal for cutting carbon steel, alloy steel, and stainless steel
Allows optimal speed selection based on material grade and cross-section.
Powerful 4 kW Main Drive Motor
Main Motor: 4 kW (5.40 HP)
Designed for continuous industrial use
Delivers consistent torque under load
Ensures stable performance across different material types.
Hydraulic Blade Tensioning & Vices
Automatic hydraulic blade tensioning
Secure hydraulic clamping system
Electrical blade monitoring (in many variants)
Improves safety, precision, and cutting reliability.
Integrated Coolant System
Built-in coolant pump
Extends blade life
Improves surface finish
Prevents overheating during heavy cuts
Compact Industrial Design
Weight: 1,800 – 2,000 kg
Industrial footprint suitable for medium-sized workshops
Easy access for maintenance and blade replacement
Up to 260 mm round and 300 x 260 mm rectangular at 90°.
Yes, it features automatic feeding and cutting cycles.
Approximately 4640 x 32 x 1.1 mm (182" x 1.25").
4 kW (5.40 HP) main drive motor.
Yes, from 30–217 m/min depending on configuration.
Carbon steel, structural steel, alloy steel, stainless steel, and profiles.
Yes, it features hydraulic vices for secure material holding.
Twin-column parallel downfeed design.
Yes, integrated coolant for improved blade life.
Fabrication shops, machine shops, steel stockists, and production units.
Yes, especially for repetitive and serial cutting tasks.
Between 1,800 and 2,000 kg.
Yes, typically industrial three-phase supply (region dependent).
Yes, hydraulic blade tensioning is standard.
For German engineering precision, durability, and reliable automatic metal cutting performance.
| Blade Length inches | 182" |
| Min/Max Blade Width | 1" to 1" |
| Machine Type | Metal |
| Round Capacity (90°) | 260 mm |
| Rectangular Capacity (90°) | 300 x 260 mm |
| Blade Thickness | 30 – 217 m/min |
| Main Drive Motor | 8 kW |
| Clamping System | Hydraulic |
| Weight | 1,800 – 2,000 kg |
| Cooling System | Integrated Coolant |
