Heavy-Duty Cutting Capacity
The HBP-360-A offers a generous 360 mm round cutting capacity and can process 360 × 360 mm flat or square material, making it ideal for medium-to-large solid stock and profiles.
Rigid Twin-Column Design
Its twin-column guided saw frame ensures exceptional rigidity and straight blade tracking, resulting in high cutting accuracy, reduced vibration, and longer blade life.
Industrial-Grade Saw Blade System
Designed for 1.5-inch (32 mm) wide blades, the machine provides excellent stability during cutting, allowing consistent results even on tough materials.
Wide Variable Cutting Speed Range
With a continuously variable cutting speed from 20 to 130 m/min, operators can easily optimize performance for different metals such as carbon steel, alloy steel, and stainless steel.
Powerful Drive Motor
Equipped with a 7.5 kW main drive motor, the HBP-360-A delivers strong torque and reliable cutting power for uninterrupted industrial operation.
Fully Automatic Operation
The automatic cutting cycle ensures consistent results, reduced operator fatigue, and higher productivity, making it suitable for batch and production cutting.
Hydraulic Material Clamping
A hydraulic clamping system ensures secure material holding, minimizing vibration and preventing movement during cutting.
Integrated Coolant System
The built-in coolant system improves surface finish, reduces heat generation, and significantly extends blade life.
Industrial Build Quality
With a machine weight of up to 3.4 tons, the HBP-360-A is built for maximum stability, long service life, and continuous industrial use.
It is an automatic horizontal metal bandsaw designed for industrial cutting.
The machine can cut round material up to 360 mm.
Yes, up to 360 × 360 mm at 90°.
Yes, it operates with an automatic cutting cycle.
It uses a 1.5-inch (32 mm) wide blade.
Yes, the cutting speed is continuously variable.
From 20 to 130 meters per minute.
The main drive motor is rated at 7.5 kW.
Yes, hydraulic material clamping is standard.
Yes, an integrated coolant system is provided.
Solid bars, tubes, profiles, and structural steel.
Absolutely, it is built for continuous industrial use.
The weight ranges from approximately 3 to 3.4 tons.
Steel service centers, fabrication shops, and heavy engineering plants.
For its accuracy, automation, durability, and high cutting capacity.
| Blade Length inches | 161" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Max. Cutting Capacity (90° – Round) | 360 mm |
| Max. Cutting Capacity (90° – Flat/Square) | 360 × 360 mm |
| Cutting Speed Range | 20 – 130 m/min |
| Main Drive Motor | 7.5 kW |
| Operation Type | Fully Automatic |
| Material Clamping | Hydraulic |
| Machine Dimensions (L × W × H) | 2950 × 2540 × 1930 mm |
| Machine Weight | 3000 – 3400 kg |
