Behringer HBP-430/854-G CNC Beam Processing Bandsaw

Heavy-Duty Structural Steel Processing

Designed specifically for beam and profile cutting, the HBP-430/854-G handles structural steel efficiently, including I-beams, H-beams, channels, and box sections.

Large Profile Capacity

Maximum profile capacity up to 600 x 340 mm, allowing processing of medium to large structural components.

CNC Controlled Operation

The integrated CNC system enables:

• Automatic cutting cycles

• Programmable mitre angles

• Length optimization

• Production data storage

• Seamless integration with drilling systems

All-Position Mitre Cutting

Mitre capability from +45° to -60°, allowing complex angled cuts required in steel construction and structural fabrication.

Automatic Material Feeding System

Equipped with a gripper measuring carriage, enabling automatic feeding of profiles up to 14 meters in length, ensuring high productivity and repeatability.

Integrated Drilling Line (Optional / Combined Configuration)

When combined with a Vernet drill unit:

• 3 independent drill spindles

• 5.5 kW power per spindle

• Drilling capacity up to 35 mm diameter

• Fully synchronized CNC control

Powerful Bandsaw Drive

Band saw motor rated at 4 kW, optimized for structural steel cutting with stable torque delivery.

Industrial Blade System

• Blade length: 283.5 inches (~7,200 mm)

• Blade width: 1.575" (40mm)

• Heavy-duty blade tensioning for stable, precise cuts

Integrated Roller Conveyor System

Includes infeed and outfeed roller conveyors for continuous material handling in automated steel processing lines.

Robust Dual-Column Construction

Ensures:

• Vibration-free cutting

• Extended blade life

• High dimensional accuracy

• Reduced maintenance requirements
