Large Cutting Capacity for Heavy Sections
Round capacity: 530 mm
Rectangular capacity: 700 x 530 mm
The machine easily handles solid bars, structural beams, pipes, and heavy profiles.
Twin-Column Guided Saw Frame
The rigid twin-column design ensures:
Maximum structural stability
Reduced vibration during cutting
Improved blade life
High dimensional accuracy
This construction makes the HBP-530 suitable for demanding industrial workloads.
Fully Automatic Hydraulic Operation
Designed for production efficiency, the machine includes:
Hydraulic material index feed
Automatic cutting cycles
Programmable feed lengths
Hydraulic clamping system
The automation reduces operator effort while maintaining consistent output quality.
Industrial-Grade Saw Blade System
Blade dimensions: approx. 7200 x 54 x 1.6 mm
Blade length: approx. 283 inches (7200 mm)
Blade width: 54 mm (2 inches)
The wide, heavy-duty blade ensures:
Smooth chip removal
Straight, accurate cuts
Excellent performance on alloy and structural steel
Powerful Main Drive Motor
Saw motor range: 7.5 kW to 12 kW
The powerful motor provides stable torque output for cutting:
Carbon steel
Alloy steel
Tool steel
Heavy structural sections
Variable Cutting Speed (Stepless Control)
Speed range: 17–110 m/min or 19–130 m/min
Variable speed allows optimization for different materials, improving blade life and cutting efficiency.
Hydraulic Material Feeding System
Automatic hydraulic index feed
Suitable for repetitive batch cutting
Ensures precision positioning
Integrated Chip Conveyor & Coolant System
Efficient chip evacuation
Reduced downtime
Cleaner work area
Extended blade life
Heavy Industrial Construction
Machine weight: approx. 2,850 kg to 4,400 kg
Robust steel frame and reinforced construction
Designed for long-term industrial operation
530 mm round and 700 x 530 mm rectangular at 90°.
Yes, it features automatic hydraulic feeding and cutting cycles.
Carbon steel, alloy steel, stainless steel, and structural profiles.
Approximately 7200 x 54 x 1.6 mm.
54 mm (2 inches).
Between 7.5 kW and 12 kW depending on configuration.
Yes, stepless speed adjustment from 17–130 m/min.
Hydraulic index feed system.
Yes, typically equipped with a chip conveyor.
Yes, the machine includes a coolant system.
Steel service centers, fabrication shops, and heavy engineering industries.
Between 2,850 kg and 4,400 kg depending on configuration.
Yes, it is designed for continuous industrial use.
Twin-column heavy-duty design.
No, this model belongs to Behringer’s industrial metal sawing division.
| Blade Length inches | 283" |
| Min/Max Blade Width | 2" to 2" |
| Machine Type | Metal |
| Max Cutting Capacity (Round 90°) | 530 mm |
| Max Cutting Capacity (Rectangular 90°) | 528×518mm |
| Blade Thickness | 1.6 mm |
| Cutting Speed | 17–110 / 19–130 m/min |
| Drive Motor Power | 7.5 – 12 kW |
| Machine Dimensions (L x W x H) | 4000 x 2250 x 3270 mm |
| Machine Weight | 2,850 – 4,400 kg |
| Coolant System | Included |
