The Cosen AH-320 is a fully automatic horizontal dual-column bandsaw designed for precise, high-volume metal cutting. With a rigid frame, inverter-driven blade speed, and HMI touch-screen control, it delivers stable performance and accuracy for steel service centers, fabrication shops, and manufacturing plants.
Dual Column Heavy-Duty Construction
The rigid dual-column frame minimizes vibration and deflection during cutting, ensuring straight, repeatable cuts even on large solid materials.
Wide Cutting Capacity
Capable of cutting round, square, and rectangular materials up to 320 mm, the AH-320 supports a broad range of industrial applications.
Hydraulic Shuttle Vise with Top Clamp
The hydraulic shuttle vise combined with a top clamp provides secure material positioning, improves cutting accuracy, and enables unattended automatic operation.
Inverter-Driven Variable Blade Speed
Blade speed can be adjusted from 20 to 100 m/min, allowing optimal performance across different materials such as mild steel, stainless steel, and alloy steel.
Carbide Blade Guide System
Carbide guides provide excellent blade support, improving cut accuracy and extending blade life during heavy-duty operation.
Advanced HMI Touch Screen Control
An intuitive HMI control panel simplifies setup, job programming, and monitoring, reducing operator fatigue and training time.
Built-In Safety and Monitoring
A blade breakage detector immediately stops machine operation in case of blade failure, enhancing safety and preventing material damage.
Production-Ready Design
Standard features such as an integral coolant system and adjustable material stop ensure smooth, continuous production with minimal downtime.
Yes, it supports fully automatic cutting with hydraulic feeding and clamping.
Steel, stainless steel, aluminum, and alloy materials.
It provides higher rigidity and more accurate cuts.
Yes, via inverter control from 20–100 m/min.
Yes, carbide guides are standard.
Yes, an integral coolant system is built in.
Yes, it is designed for continuous industrial operation.
Yes, a blade breakage detector is included.
HMI touch screen control.
Yes, a hydraulic shuttle vise with top clamp.
Absolutely, it is ideal for high-volume cutting.
Yes, automatic operation minimizes manual handling.
Very high accuracy due to rigid construction and carbide guides.
Yes, the machine is designed for easy access and servicing.
Yes, inverter-driven blade speed improves energy efficiency.
| Blade Length inches | 167" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Cutting Capacity (Round) | 320 mm (12.6") |
| Cutting Capacity (Square) | 320 mm (12.6") |
| Cutting Capacity (Rectangle H x W) | 380 x 320 mm (15" x 12.6") |
| Blade Size (L x W x T) | 4240 x 34 x 1.1 mm |
| Blade Speed | 20 – 100 m/min (Inverter Driven) |
| Saw Blade Motor | 3.75 kW (5 HP) |
| Hydraulic Motor | 0.75 kW (1 HP) |
| Power Supply | 380V / 3 Phase |
| Machine Weight | Approx. 1,700 kg (3,750 lbs) |
| Dimensions (L x W x H) | Approx. 1890 x 1905 x 1700 mm |
