Heavy-Duty Dual-Column Design
Rigid dual-column construction for maximum cutting stability
Heavy cast-iron frame minimizes vibration
Ensures consistent accuracy on large workpieces
High Cutting Capacity
Round: up to 520 mm (20.5")
Rectangular: up to 520 × 560 mm (20.5" × 22")
Bundle cutting: approx. 250 – 470 mm width
Ideal for solid bars, pipes, tubes, and structural bundles
Powerful Blade Drive System
7.5 HP or 10 HP blade motor (5.6 kW option)
Maintains stable cutting torque on large cross-sections
Suitable for tough alloys and carbon steel
Wide & Durable Blade System
Blade size: ~250" × 2" × 0.063"
Metric equivalent: 6040 × 54 × 1.6 mm
Supports blade widths from 1.5" to 2"
Designed for straight, high-accuracy cutting
Variable Blade Speed Control
Blade speed range: 50 – 328 FPM (15 – 100 m/min)
Adjustable for different materials and profiles
Enhances surface finish and blade life
SNC-100 Programmable NC Control
HMI touchscreen interface
Stores multiple cutting programs
Automatic kerf compensation
Simple job setup and repeatability
Automatic Feeding & Indexing
NC-controlled automatic material feed
Ensures consistent cut lengths
Ideal for batch and continuous production
Hydraulic Full-Stroke Vises
Powerful hydraulic clamping system
Full-stroke vises securely hold large materials
Split jaw design reduces burr formation
Automatic Hydraulic Blade Tensioning
Maintains optimal blade tension
Protects the blade during operation
Extends blade service life
Carbide Blade Guides
Tungsten carbide blade guides and bearings
Superior blade support under high cutting pressure
Improved straightness and accuracy
Integrated Coolant & Chip Management
Flood coolant system for heat control
Hydraulic chip conveyor for automatic chip removal
Keeps the cutting area clean and productive
Vibration Dampening System
Production-Ready Automation
Minimal operator intervention required
Consistent performance across long shifts
Optimized for industrial throughput
Low Maintenance & Long Service Life
Versatile Industrial Applications
