Heavy-Duty Industrial Build
Rigid steel frame minimizes vibration and blade deflection
Designed for long-term industrial use
Ensures stable, accurate cuts even on solid materials
Versatile Cutting Capacity
Round cutting capacity:
10" at 90°
9.1" at -45°
4.3" at -60°
Rectangular cutting capacity:
9.1" × 18.1" at 90°
9.1" × 9.1" at -45°
9.1" × 4.3" at -60°
Suitable for pipes, profiles, flats, and solid bars
Manual Mitering Saw Head
Swiveling saw head for angle cuts
Miter range from 90° to 30° (negative angles)
Ideal for fabrication and structural steel work
Stable 1-Inch Blade System
Uses 1-inch wide bandsaw blades
Excellent beam strength for straight, accurate cutting
Reduced blade wander and improved surface finish
Multiple Blade Speed Options
Four selectable blade speeds:
75 / 121 / 190 / 305 FPM
(Alternate configuration: 95 / 150 / 213 / 321 FPM)
Optimized cutting for mild steel, stainless steel, and alloys
Powerful Blade Drive Motor
2 HP blade motor delivers consistent torque
Smooth cutting performance across material sizes
Reliable operation in continuous shop use
Carbide Blade Guides
Tungsten carbide blade guides with bearings
Maintains precise blade tracking
Extends blade life and improves cut accuracy
Hydraulic Downfeed Control
Hydraulic cylinder-controlled downfeed
Adjustable cutting pressure for different materials
Ensures smooth and chatter-free cutting
Robust Cast Iron Vise
Heavy-duty cast iron vise with replaceable plates
Secure clamping for stable and accurate cuts
Ideal for both straight and angled cutting
Integrated Coolant System
Built-in flood coolant system
10.6-gallon coolant tank
Reduces heat buildup and extends blade life
Operator-Friendly Design
Comfortable workbed height (~25.2" – 25.4")
Simple controls for easy operation
Compact footprint suitable for small and medium workshops
It is a manual mitering horizontal metal bandsaw.
10 inches at 90 degrees.
Can it perform angled cuts?
It uses a 1-inch wide blade.
Approximately 137–138 inches.
Four selectable blade speeds.
A 2 HP blade drive motor.
Yes, carbide blade guides are standard.
Via a hydraulic downfeed cylinder with adjustable pressure.
Does the machine include a coolant system?
Carbon steel, alloy steel, stainless steel, and non-ferrous metals.
The vise is a heavy-duty cast iron manual vise.
Yes, it is ideal for fabrication, welding, and metal workshops.
Typically 220V, 3-phase, 60Hz (460V optional).
Yes, it is designed for low maintenance with durable components.
| Blade Length inches | 137" |
| Min/Max Blade Width | 1" to 1" |
| Machine Type | Metal |
| Cutting Capacity – Round (90°) | 10" |
| Cutting Capacity – Round (-45°) | 9.1" |
| Cutting Capacity – Round (-60°) | 4.3 |
| Cutting Capacity – Rectangular (90°) | 9.1" × 18.1" |
| Cutting Capacity – Rectangular (-45°) | 9.1" × 9.1" |
| Cutting Capacity – Rectangular (-60°) | 9.1" × 4.3" |
| Blade Thickness | 0.035 inch |
| Blade Speed | 75 / 121 / 190 / 305 FPM |
| Blade Motor | 2 HP |
| Coolant System | Flood Coolant (10.6-gallon tank) |
| Coolant Motor | 1/8 HP |
| Workbed Height | ~25.2" – 25.4" |
| Electrical | 220V / 3-Phase / 60Hz (460V optional) |
| Machine Weight | Approx. 1,430 – 1,442 lbs |
