Swivel-Head Miter Cutting Design
The AH-330-ER features a swivel saw head allowing forward miter cutting from 90° to 30°, eliminating the need to reposition material and improving workflow efficiency.
Versatile Cutting Capacity
Supports round, square, and rectangular materials, making it suitable for a wide range of structural profiles, bars, and tubing.
Semi-Automatic Hydraulic Operation
Hydraulic frame lift and hydraulic vice operation reduce operator effort while maintaining precise and repeatable cutting cycles.
Multi-Step Blade Speed Selection
Multiple blade speed options for both 50 Hz and 60 Hz power systems allow operators to match cutting speed with material hardness and size.
Tungsten Carbide Blade Guides
High-quality carbide blade guides provide excellent blade stability, improved cutting accuracy, and extended blade life.
Quick Cam-Lock & Hydraulic Movable Vice
Ensures fast material clamping, secure holding, and consistent cutting alignment.
Compact and Shop-Friendly Design
With a relatively small footprint and moderate weight, the AH-330-ER fits easily into fabrication shops with limited floor space.
Integrated Coolant System
Helps control heat, improve surface finish, and increase blade longevity during extended cutting operations.
No, it is a semi-automatic bandsaw with hydraulic frame lift and vice operation.
Yes, it supports forward miter cuts from 90° to 30°.
Mild steel, stainless steel, aluminum, and structural sections.
Up to 330 mm (13 inches) at 90°.
Yes, via multi-step speed selection based on power frequency.
Yes, tungsten carbide blade guides are standard.
Yes, an integrated coolant system is provided.
Quick cam-lock with a hydraulic movable vice.
Yes, it is ideal for fabrication and general workshop use.
Yes, up to 270 x 460 mm at 90°.
Yes, it features simple controls and semi-automatic operation.
Very accurate due to the rigid frame and carbide blade guides.
No, it has a compact footprint for its capacity.
No, it is designed for easy maintenance and service access.
Yes, it is well-suited for such applications.
| Blade Length inches | 163" |
| Min/Max Blade Width | 1" to 1" |
| Machine Type | Metal |
| Miter Cutting Range | 90° to 30° (Forward) |
| Cutting Capacity – Round (90°) | 330 mm (13") |
| Cutting Capacity – Square (90°) | 270 mm (10.6") |
| Cutting Capacity – Rectangle (90°) | 270 x 460 mm (10.6" x 18") |
| Blade Size (L x W x T) | 4150 x 27 x 0.9 mm |
| Blade Speeds (50 Hz) | 19, 30, 42, 63 m/min |
| Blade Speeds (60 Hz) | 23, 36, 51, 76 m/min |
| Saw Blade Motor | 2 HP (1.5 kW) |
| Hydraulic Motor | 0.5 HP (0.375 kW) |
| Coolant Pump Motor | 0.125 HP (0.1 kW) |
| Net Weight | Approx. 640 kg (1,408 lbs) |
| Floor Space (L x W x H) | 2100 x 1650 x 1400 mm |
