The Delta 28-140 is a versatile 3-wheel bandsaw, perfect for woodworking shops, schools, and small manufacturing. It offers stable tracking, large cutting capacity, and flexible blade options, making it ideal for both straight and curved cuts. With a wide throat, tall cutting height, and tilting table, it ensures reliable performance for detailed woodworking tasks.
3-Wheel Bandsaw Design
Unique 3-wheel configuration allows a compact footprint
Provides smooth blade tracking and stable cutting
Suitable for tight-radius curves and detailed work
Generous Cutting Capacity
Maximum cutting height of approximately 13-1/4 inches
Throat width of about 19-1/4 inches
Handles large panels, boards, and thick stock with ease
Wide Blade Compatibility
Supports blade widths from 1/8 inch to 1/2 inch
Compatible with various tooth configurations (TPI)
Allows easy switching between straight cuts and fine detail work
Precision Tilting Work Table
Table tilts 45° to the right and 12° to the left
Enables bevel and angled cuts
Ideal for joinery and custom woodworking projects
Smooth Cutting Performance
Designed for clean cuts in hardwoods and softwoods
Capable of cutting plastics and non-ferrous materials with proper blades
Maintains consistent performance across different materials
Blade Versatility
Accepts blades with different TPI ratings
Lower TPI for fast rip cuts
Higher TPI for scroll work and fine detailing
User-Friendly Operation
Simple blade changes and adjustments
Designed for ease of use in workshops and learning environments
Balanced design helps reduce vibration during cutting
It is a 3-wheel woodworking bandsaw.
Wood, plastic, and non-ferrous metals with suitable blades.
Approximately 13-1/4 inches.
About 19-1/4 inches.
From 1/8 inch to 1/2 inch.
Approximately 72 inches.
Yes, 45° right and 12° left.
Yes, especially with narrow blades.
High Carbon Steel (HCS).
Yes, with higher TPI blades.
Yes, it is designed for everyday shop use.
Yes, with proper blade selection and speed.
No, it is designed for easy blade changes.
Woodworking shops, schools, and hobby workshops.
Yes, through its tilting table design.
| Blade Length inches | 72.625" |
| Min/Max Blade Width | 1/8" to 1/2" |
| Machine Type | Wood |
| Cutting Height (Max) | Approx. 13-1/4 inches |
| Throat Width | Approx. 19-1/4 inches |
| Supported Blade Widths | 1/8", 1/4", 3/8", 1/2" |
| Table Tilt | 45° Right, 12° Left |
| Blade Material | High Carbon Steel (HCS) |
| TPI Range | Varies (6–14 TPI typical) |
| Machine Configuration | 3-Wheel Design |
| Cutting Style | Straight & curved cuts |
| Operation Type | Manual |
