Delta 28-269 TYPE 1 – Reliable 14" Woodworking Bandsaw

MAIN FEATURES

Versatile 14" Cutting Capacity: A full 14" throat capacity allows users to cut wide panels, curves, and detailed patterns with ease.

Supports 93.5" Blades: Runs standard 93.5" blades and accepts 1/8" to 3/4" widths for fine detail work, general cutting, and light resawing.

Stable Cast-Iron Frame: Heavy cast-iron construction minimizes vibration and keeps cuts smooth and accurate under load.

Large Cast-Iron Table: Provides a flat, durable 14" class work surface ideal for furniture components and precision projects.

Smooth Blade Tracking System: Adjustable blade guides keep the cut aligned and stable during tight curves and straight cuts.

Expandable Cutting Height: Factory 6" cutting height can be increased to approx. 12" with an optional Delta riser block (commonly used on this series).

Reliable Motor Compatibility: Typically paired with a 3/4 HP or 1 HP motor, offering consistent performance for most woodworking tasks.

Easy Blade Changes: Quick-tensioning and accessible guide adjustments make blade swaps fast and user-friendly.

COMMON QUESTIONS

It uses a standard 93.5" blade.

From 1/8" to 3/4", suitable for curves, straight cutting, and light resawing.

14 inches, the standard for Delta’s classic 14" bandsaw lineup.

Approximately 6", expandable to ~12" with a riser block.

Yes, the saw uses a durable cast-iron frame and table.

Yes, this model is compatible with Delta’s 6" riser block kit.

Typically 3/4 HP–1 HP for optimal performance.

Yes, with narrow blades (1/8"–1/4") it excels at detail curve cutting.

Light-duty resawing is possible; riser block improves capacity.

Primarily wood, but plastics and light non-ferrous materials can be cut using proper blades.

Many units include a dust port or can be fitted with aftermarket 4" dust ports.

Yes, guides, bearings, and tensioning components are easy to access.

Yes, compact footprint makes it ideal for home shops.

Many aftermarket and OEM-compatible parts remain widely available.

It offers proven reliability, smooth operation, and versatile cutting capacity in a classic 14" design.

SPECIFICATION

PRODUCT VIDEO

DOWNLOADABLE RESOURCES

REVIEWS

BLOG

SPECIFICATIONS

Blade Length inches	93.5"
Min/Max Blade Width	1/8" to 3/4"
Machine Type	Wood
Throat Capacity	14 inches
Max Cutting Height	6 inches (12" with riser block)
Frame Material	Cast Iron
Table Size	14″ x 14″ or larger
Motor Power	Likely 1-1.5 HP
Applications	Curve cutting, ripping, light resawing, general woodworking

Delta 14” – 360 Video Demo for this Delta 14” Roller Guide Upgrade Kit for your band saw

Category Video, Guides, Wood

Delta 14” – 360 Video Demo for this Delta 14” Roller Guide Upgrade Kit for your band saw

Optimize Your Delta 14” Bandsaw with the Black Iron Roller Guide Upgrade Kit [DLT14] The Black Iron Roller Guide Upgrade Kit is part of the Black Iron Guide Kits lineup, designed to deliver precision, straighter cuts, and extended blade life for your Delta 14” bandsaw. With this upgrade, woodworkers and fabricators can expect improved cutting accuracy, smoother operation, and greater reliability on every project. This 360 Video Demo showcases the full system, highlighting the upper guides, lower guides, mounting brackets, and studs, so you can see the build quality and design details before installation. Crafted from high-grade aluminum and equipped with sealed roller bearings, this guide kit ensures durability, blade stability, and reduced vibration during operation. Optimized to work with Carbon Bandsaw Blades, it provides dependable results, cleaner cuts, and consistent performance ac...
