The Delta 28-641 is a 20-inch vertical bandsaw built for professional woodworking, offering smooth performance and light-duty combo capability. With a large throat, high cutting capacity, and 156.5-inch blade compatibility, it’s ideal for resawing and precision cuts in workshop settings.
Professional 20-Inch Woodworking Bandsaw
Designed for heavy-duty woodworking operations
Vertical bandsaw configuration ideal for resawing and curved cuts
Suitable for hardwoods, softwoods, plywood, and laminates
Wide Blade Compatibility
Accepts blades from 0.25 inch to 1 inch width
Uses 156.5-inch continuous bandsaw blades
Supports a wide range of TPI options for rough cutting to fine finishing
Large Throat & Cutting Height
Approximate 21-inch throat capacity allows cutting wide panels
20.5-inch height under guide enables thick stock and resaw work
Excellent for slab cutting and book-matching applications
Stable & Rigid Construction
Heavy-duty cast iron and steel frame minimizes vibration
Large balanced wheels ensure smooth blade travel
Designed for consistent accuracy during long cutting cycles
Powerful Three-Phase Motor
Typically configured for 230V three-phase power
Delivers steady torque for dense hardwood cutting
Industrial-grade reliability for continuous shop use
Precision Blade Tracking & Guide System
Adjustable blade guides provide accurate blade support
Manual tracking adjustment keeps the blade centered
Improves cut accuracy and extends blade life
Large Cast Iron Work Table
Table size approximately 21" x 20.5"
Provides excellent support for large and heavy workpieces
Suitable for straight cuts, curves, and resaw operations
Workshop-Ready Safety & Electrical Design
Recommended #12 power cord with time-lag fuse protection
Stable electrical setup ensures safe, uninterrupted operation
It is a 20-inch vertical woodworking bandsaw with combo capabilities.
The machine uses 156.5-inch continuous bandsaw blades.
Blade widths from 0.25 inch to 1 inch.
Yes, it is excellent for resawing thick hardwoods.
Approximately 21 inches from blade to column.
About 20.5 inches under the blade guide.
Typically 230V three-phase power.
Yes, the Delta 28-640 is the single-phase variant.
It is primarily designed for woodworking; light non-ferrous materials may be possible with proper blades.
Hardwood, softwood, plywood, laminates, and similar materials.
Yes, up to 1-inch wide blades.
A heavy-duty cast iron table.
Yes, via manual top-wheel tracking adjustment.
Yes, 156.5-inch blades are commonly available.
Yes, it is built for industrial and professional woodworking environments.
| Blade Length inches | 156.5" |
| Min/Max Blade Width | 1/4" to 1" |
| Machine Type | Combo |
| Throat Capacity | 21 inches |
| Height Under Guide | 20.5 inches |
| Blade Speed | Variable (woodworking optimized) |
| Power Supply | 230V, Three-Phase |
| Table Size | 21" x 20.5" |
| Frame Construction | Cast iron / Steel |
| Blade Guide System | Adjustable |
| Primary Applications | Wood cutting, resawing |
Delta 20" D Band Saw Guides – Black Iron Guide Kit for Precision and Power
Sawblade.com presents the Delta 20" D Band Saw Guides – Black Iron Guide Kit, an advanced guide upgrade kit that transforms the cutting capability of your Delta bandsaw. In this video, product specialist Leslie showcases this rugged, high-performance solution designed for woodworkers seeking unmatched reliability, pinpoint precision, and enhanced cutting control. Built from high-grade aluminum and featuring sealed performance ball bearings, this Black Iron Guide Kit offers a massive improvement over factory blade guides. The triple-bearing design includes two adjustable front bearings for lateral blade support and pinpoint accuracy, as well as a rear thrust bearing that rolls with the blade to minimize friction, heat, and wear. This setup drastically reduces vibration and horizontal blade walk, allowing for cleaner, straighter cuts, whether you're resawing thick stock or performing detai...
