1. 16” Throat Capacity for Flexible Cutting
The DoAll 16-2 provides:
16-inch throat depth for medium-sized workpieces
Ideal for contour cutting, profiling, and internal shapes
Suitable for both metal and non-ferrous materials
2. Dual-Range Infinitely Variable Speed
Advanced speed control system:
Low Range: 50 – 300 FPM (for metals)
High Range: 850 – 5,200 FPM (for wood/plastics)
Infinitely variable adjustment
Optimized cutting for different materials
This ensures precision, reduced heat, and longer blade life.
3. Wide Blade Width Range (1/16” to 1”)
Supports multiple applications:
Narrow blades for intricate contour cutting
Wider blades for straight cutting and resawing
Maximum flexibility for different job types
4. Large 24” x 24” Work Table
The spacious table offers:
Better support for larger workpieces
Improved operator control
Enhanced stability during cutting
5. Tilting & Adjustable Work Setup
Adjustable work height up to 10”–12”
Ideal for varied material thickness
Allows precise positioning for accurate cuts
6. Optional Built-in Blade Welder System
Many units are equipped with:
Butt welder for blade joining
Grinder for finishing welds
Enables internal contour cutting
Reduces downtime and blade costs
7. Powerful 1.5–3 HP Motor
Smooth cutting performance
Adequate power for metal cutting
Energy-efficient operation
Low vibration for better accuracy
8. Heavy-Duty Construction
Weight: 1,100 – 1,500 lbs
Rigid frame design
Long-lasting durability
Stable cutting performance
9. Workshop-Friendly Design
Compact footprint
Easy-to-use controls
Suitable for toolrooms, fabrication shops, and maintenance units
It has a 16” throat capacity.
It is a vertical contour bandsaw.
From 1/16” up to 1” width.
Approximately 119.5” to 122”.
Yes, with dual-range infinitely variable speeds.
Between 1.5 HP and 3 HP.
24” x 24”.
Yes, it is ideal for intricate contour work.
Many units include an integrated blade welder.
Steel, aluminum, plastics, and non-ferrous materials.
Yes, for light to medium production.
Up to 10”–12”.
Yes, with basic training.
No, it has a compact footprint.
Toolrooms, fabrication, maintenance, and prototyping.
| Blade Length inches | 119.5" |
| Min/Max Blade Width | 1.25" to 1.5" |
| Machine Type | Metal |
| Throat Capacity | 16” (405 mm) |
| Max Work Height | 10” – 12” |
| Table Size | 24” x 24” |
| Blade Speed | 50 – 300 FPM / 850 – 5,200 FPM |
| Motor Power | 1.5 – 3 HP |
| Weight | Approx. 1,100 – 1,500 lbs |
| Blade Welder | Optional (built-in) |
