1. 10-1/4” x 12” Cutting Capacity
The DoAll C-260-A efficiently handles:
Round bar stock up to 10-1/4” diameter
Rectangular material up to 10-1/4” x 12”
Structural shapes, tubing, and solid alloy blocks
This makes it ideal for medium-capacity fabrication work.
2. 5 HP Main Drive Motor
The powerful 5 HP motor ensures:
Smooth cutting performance
Strong torque for thick materials
Reduced blade deflection
Consistent production output
Perfect for continuous industrial operation.
3. Infinitely Variable Blade Speed (60–350 FPM)
The adjustable speed control allows operators to:
Optimize speed for different metals
Improve surface finish quality
Extend blade lifespan
Reduce heat and wear
Suitable for carbon steel, stainless steel, aluminum, and alloys.
4. Heavy-Duty Blade System
Blade Size: Typically 144” x 1-1/4” x .042” or .045”
Blade Width: 1.25”
High-tension blade support
Stable tracking for accurate cuts
The wider blade improves rigidity and minimizes vibration.
5. Hydraulic Feed & Clamping System
The C-260-A features hydraulic control for:
Smooth and consistent downfeed
Secure material clamping
Reduced operator effort
Improved repeatability
Ensures straight, burr-minimized cuts.
6. Industrial Power Configuration
Standard Voltage: 230V or 460V
3-Phase Electrical System
Designed for industrial workshop compatibility
7. Compact Yet Heavy-Duty Construction
Approximate Dimensions: 90” L x 63” W x 48” H
Weight: 4,200 – 5,000 lbs
Rigid welded steel frame
Designed to minimize vibration
Built for long-term reliability in production environments.
10-1/4” round and 10-1/4” x 12” rectangular.
Typically 144 inches (varies by configuration).
1.25 inches.
60 to 350 FPM, infinitely variable.
A 5 HP main drive motor.
Yes, it features automatic hydraulic feed.
Steel, stainless steel, aluminum, and alloy materials.
230V or 460V, 3-phase power.
Yes, ideal for medium-duty production environments.
Yes, due to its rigid industrial frame.
Fabrication, automotive, tool & die, and service centers.
Yes, fully adjustable.
Between 4,200 and 5,000 lbs.
Yes, typically equipped with coolant system (varies by configuration).
Yes, suitable for repeat production cuts.
| Blade Length inches | 144" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Blade Size | 144” x 1-1/4” x .042” / .045” |
| Round Capacity | 10-1/4” (260 mm) |
| Rectangular Capacity | 10-1/4” x 12” (260 x 305 mm) |
| Blade Speed | 60 – 350 FPM |
| Main Motor | 5 HP |
| Electrical | 230V / 460V, 3-Phase |
| Machine Dimensions | Approx. 90” x 63” x 48” |
| Machine Weight | Approx. 4,200 – 5,000 lbs |
