1. 10.6" (270 mm) Cutting Capacity
Round Capacity: Approx. 10.6" (270 mm)
Rectangular Capacity: Up to 10" x 12" or 12" x 16" (frame dependent)
Square Capacity: Approx. 10" x 10" to 12.5" x 12.5"
Suitable for cutting solid bars, structural sections, and pipe materials.
2. Heavy-Duty Production Frame
Rigid welded steel construction
Designed for vibration-free cutting
Built for continuous production environments
The industrial-grade frame enhances stability and accuracy.
3. Infinitely Variable Blade Speed
Blade Speed Range: 60–350 FPM (18–107 m/min)
Adjustable for various material types
Optimizes cutting efficiency and blade life
4. Powerful Industrial Drive Motor
Motor Power Range: 2 HP to 5 HP (model configuration dependent)
Designed for consistent torque
Handles alloy steels and structural materials efficiently
5. Precision Blade System
Blade Length: 138"
Blade Width: 1-1/4"
Blade Thickness (typical): 0.042"
Carbide-faced, spring-loaded blade guides
Ensures straight, accurate cuts with minimal deflection.
6. Hydraulic Feed & Clamping Controls
Hydraulic head feed rate adjustment
Hydraulic vise clamping pressure
Smooth, controlled cutting cycle
Improves productivity while reducing operator fatigue.
7. Automatic Indexing System
Single Stroke Feed: 20"–24" typical
Designed for repetitive batch cutting
Increases production efficiency
8. Recirculating Coolant System
Tank capacity: Approx. 15–20 gallons
Improves blade life
Enhances surface finish
9. Advanced Safety Features
Blade door interlocks
Automatic blade break detection
Emergency stop controls
Ensures safe industrial operation.
10. Industrial-Grade Weight & Build
Machine Weight: Approx. 1,700–3,600 lbs
Footprint: Approx. 80" x 80"
Pass-line Height: 27"–29"
Designed for stability and heavy-duty shop environments.
11. Carbide Blade Guides
Spring-loaded carbide inserts
Improved cut precision
Reduced blade wear
12. Production-Ready Automation
The DoAll C-270 is typically configured for automatic operation, making it ideal for:
Steel service centers
Fabrication workshops
Maintenance departments
Production manufacturing lines
Approximately 10.6 inches (270 mm).
Yes, most configurations are automatic production models.
1-1/4" x 0.042" x 138".
Yes, infinitely variable between 60–350 FPM.
Typically between 2 HP and 5 HP depending on configuration.
Yes, it is designed for structural shapes and solid bars.
Yes, a recirculating coolant system is standard.
Carbide-faced, spring-loaded blade guides.
Approximately 80" x 80".
Yes, hydraulic vise clamping is standard.
Fabrication, steel processing, manufacturing, maintenance shops.
Typically 20–24 inches per stroke.
Yes, blade door interlocks and blade break detection.
Carbon steel, alloy steel, stainless steel, aluminum.
It offers production-grade automation, precision cutting, and industrial durability.
| Blade Length inches | 144" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Round Cutting Capacity | 10.6" (270 mm) |
| Rectangular Capacity | Up to 10" x 12" / 12" x 16" |
| Square Capacity | 10" x 10" to 12.5" x 12.5" |
| Blade Thickness | 0.042" (typical) |
| Blade Speed | 60–350 FPM (variable) |
| Motor Power | 2–5 HP (configuration dependent) |
| Indexing Stroke | 20–24 inches (single stroke typical) |
| Coolant Tank Capacity | 15–20 gallons |
| Machine Weight | 1,700–3,600 lbs |
| Footprint | Approx. 80" x 80" |
