1. Integrated Blade Welder, Grinder & Shear
The DBW-1A includes a complete blade management system:
Built-in butt welder for blade joining
Annealer for strengthening weld joints
Grinder for smoothing weld seams
Blade shear for precise cutting
This eliminates dependency on external blade suppliers and reduces downtime.
2. Large 26” Throat Capacity
The wide throat capacity allows:
Cutting of large workpieces
Complex contour shapes
Internal cutouts and intricate profiles
Ideal for tool making and custom fabrication work.
3. Spacious 30” x 30” Work Table
The large work surface offers:
Better material support
Improved operator control
Stability for large plates and components
4. Tilting Table for Angular Cuts
45° tilt to the left
10° tilt to the right
Enables:
Bevel cutting
Precision angled operations
Versatility in fabrication
5. Variable Blade Speed (50–2000 SFM)
Wide speed range ensures:
Compatibility with different metals
Better control for contour cutting
Reduced heat and blade wear
Smooth finishes on intricate cuts
6. Precision Contour Cutting Capability
Vertical design allows:
Freehand cutting
Radius and profile cutting
Tool and die work
Artistic and custom metal shaping
7. Compact Yet Powerful Design
Efficient use of floor space
Heavy-duty frame for stability
Suitable for tool rooms and workshops
8. Flexible Power Options
Operates on 220V power supply
Available in both single-phase and three-phase configurations
It is used for vertical contour cutting and in-house blade welding/repair.
Yes, it has an integrated welder, annealer, grinder, and shear.
Approximately 26 inches.
122” length with 0.5” width.
Around 30” x 30”.
Yes, 45° left and 10° right.
Variable from 50 to 2000 SFM.
Yes, ideal for intricate and curved cuts.
Tool rooms, fabrication shops, and maintenance units.
Yes, up to approximately 12” work height.
No, it has a built-in blade welder.
220V.
More suited for custom, precision, and tool room work.
Yes, by welding the blade through drilled holes.
Yes, but some experience is recommended for welding and contour cutting.
| Blade Length inches | 122" |
| Min/Max Blade Width | 1/2" to 1/2" |
| Machine Type | Metal |
| Throat Capacity | Approx. 16” |
| Maximum Work Height | Approx. 12” |
| Table Size | 30” x 30” |
| Table Tilt | 45° Left, 10° Right |
| Blade Speed | 50 – 2000 SFM (Variable) |
| Voltage | 220V |
| Phase Options | Single-phase / Three-phase |
| Machine Type | Metal Cutting |
