1. Large 20” x 21” Cutting Capacity
The TF-2021-NC handles:
Rectangular sections up to 20” x 21”
Large structural beams and solid blocks
Heavy alloy and tool steel materials
Designed for fabrication shops that process oversized material on a daily basis.
2. Powerful 10 HP Main Drive Motor
The high-output 10 HP motor delivers:
Strong torque for thick sections
Stable cutting under heavy loads
Reduced blade deflection
Faster cycle times
Perfect for production-level cutting of demanding materials.
3. NC Control System for Automated Precision
The integrated NC control system allows:
Programmable cut lengths
Automatic multi-indexing
Consistent repeat accuracy
Reduced operator intervention
This improves production efficiency and reduces labor costs.
4. Variable Blade Speed (50–300 FPM)
Adjustable blade speed enables:
Material-specific optimization
Extended blade life
Improved cut finish
Lower heat generation
Operators can easily fine-tune settings for mild steel, stainless steel, or hardened alloys.
5. 0–24” Automatic Indexing Stroke
The programmable indexing system provides:
Up to 24-inch feed stroke
Accurate repeat cutting
Efficient long stock processing
Reduced setup time
Ideal for batch cutting applications.
6. Bi-Directional Head Tilt (Right or Left)
The saw head can tilt:
Right or left for angled cutting
Improved fabrication flexibility
Increased versatility for structural components
7. Heavy-Duty Blade System
Blade Size: 192” x 1-1/4” x 0.042”
Blade Width: 1.25”
High-tension cutting stability
Reduced vibration
Designed for precision and durability in heavy cutting environments.
8. Large Work Table (28” x 42-1/2”)
The spacious table supports:
Large structural materials
Stable material positioning
Improved safety and handling
9. Industrial-Grade Construction
Machine Weight: Approx. 7,865 lbs (3,567 kg)
Dimensions: Approx. 113.5” x 117” x 118” H
Rigid welded frame
Designed for continuous production use
It cuts rectangular material up to 20” x 21”.
It features a powerful 10 HP motor.
Approximately 192–193 inches.
1.25-inch blade width.
Yes, it includes NC programmable automatic operation.
50 to 300 feet per minute.
Yes, the head tilts right or left.
Up to 24 inches.
Yes, it is designed for heavy industrial production.
Carbon steel, stainless steel, aluminum, and alloys.
Approximately 7,865 lbs.
28” x 42-1/2”.
Yes, especially large cross-sections.
Yes, through programmable NC control.
Absolutely — it is built for continuous operation.
| Blade Length inches | 192" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Metal |
| Blade Size | 192” x 1-1/4” x 0.042” |
| Cutting Capacity (Rectangular) | 20” x 21” |
| Blade Speed | 50 – 300 FPM |
| Main Motor | 10 HP |
| Indexing Stroke | 0 – 24” |
| Table Size | 32"x36 |
| Machine Weight | Approx. 7,865 lbs |
| Machine Dimensions | Approx. 113.5” x 117” x 118” H |
