162-Inch Blade Length
The specified Wellsaw 1216A replacement blade features a 162-inch blade length. Correct blade length is essential for proper installation, tensioning, tracking, and safe machine operation.
1- to 1.25-Inch Blade Width Compatibility
The specified blade-width range is 1 to 1.25 inches, allowing selection of a suitable blade profile based on the machine configuration and cutting requirements.
Automatic Production Cutting
The compatible 1216A platform is designed for automatic production cutting, supporting repeatable cutting cycles while reducing manual intervention during high-volume operations.
Automatic Material Feeding
Automatic bar-feed systems can provide feed strokes of up to approximately 24 inches, helping maintain consistent material positioning and efficient repetitive production.
Hydraulic Blade Tensioning
The compatible machine platform uses hydraulic blade tensioning to maintain consistent blade loading, improve tracking, and reduce the risk of improper blade setup.
Variable Hydraulic Feed Force
The supplied specifications identify an adjustable feed-force range of approximately 0 to 300 lbs, allowing cutting pressure to be matched to material type and section size.
Premium Blade Guide Support
Heavy-duty carbide blade guides combined with backup rollers help stabilize the blade and maintain accurate tracking through demanding metal-cutting operations.
High-Capacity Cutting Performance
The compatible 1216A series provides approximately 12 inches high × 16 inches wide rectangular capacity, with larger envelopes available on some machine generations.
Large Round Cutting Capacity
Depending on the machine configuration, the platform can accommodate round workpieces measuring approximately 12.75 to 15 inches in diameter.
Infinitely Variable Blade Speed
The compatible machine provides an approximate blade-speed range of 65 to 390 SFPM, allowing operators to select suitable cutting conditions for different metals.
45-Degree Swivel Vise Compatibility
Compatible machine configurations can use quick-acting or swivel vise systems for secure workholding and angled cutting applications.
Integrated Wet-Cutting System
The machine platform includes a wet-cutting fluid system that helps cool the cutting zone, reduce friction, flush chips, and support longer blade life.
Synchronized Blade Cleaning
A built-in or synchronized blade brush helps remove chips from the blade teeth during operation, supporting cleaner cutting and more consistent tooth engagement.
Stable Blade Tracking
Correct blade tension, guide adjustment, wheel condition, tooth selection, and machine alignment help maintain reliable tracking throughout automatic production cycles.
Extended Blade Service Life
Correct tooth pitch, break-in procedure, cutting speed, feed force, tension, coolant management, and routine machine maintenance can help minimize premature wear and extend blade life.
