1. Industry-Proven Thin-Kerf Sawmilling Technology
The LT15 utilizes Wood-Mizer's renowned narrow-band blade technology to maximize lumber recovery.
Benefits:
Produces more boards per log
Generates less sawdust waste
Requires lower power consumption
Increases profitability from every log
This thin-kerf system is one of the primary reasons Wood-Mizer sawmills are widely used worldwide.
2. Large Log Processing Capacity
Depending on the LT15 configuration, operators can process substantial timber sizes.
Standard Models:
Maximum Log Diameter: 27.5" (70 cm)
Maximum Width of Cut: 25.2" (64 cm)
LT15 CLASSIC WIDE:
Maximum Log Diameter: 35" (90 cm)
Maximum Width of Cut: 34" (86 cm)
This allows users to mill everything from dimensional lumber to large live-edge slabs.
3. Modular Bed Design for Unlimited Expansion
One of the LT15's most valuable features is its modular rail bed system.
Advantages:
Standard cutting length: 17' 8"
Additional bed extensions available
Expandable using 6' 8" modular sections
Accommodates longer logs and timber projects
The expandable design allows the sawmill to grow with your business.
4. Multiple Engine and Power Options
The LT15 is available with several power configurations.
Available Options:
Gasoline Engines
14 HP Kohler/Vanguard
19 HP Kohler/Vanguard
25 HP Kohler/Vanguard
Electric Motors
5.5 kW
7.5 kW
11 kW
This flexibility allows users to choose the power source best suited to their operation.
5. Precision Blade System
The LT15 uses a premium bandsaw blade configuration:
Blade Length: 158"
Blade Width: 1.25"
Blade Thickness: 0.042"
Combined with Wood-Mizer's blade technology, this delivers excellent cutting accuracy and board quality.
6. Dynamically Balanced Steel Band Wheels
The machine features large 19-inch steel band wheels engineered for smooth operation.
Benefits:
Reduced vibration
Improved blade tracking
Better blade life
Consistent cutting performance
7. Manual Feed with Optional Power Feed
The standard LT15 includes a manual push-feed system.
Optional Upgrade:
12V Power Feed System
Reduced operator fatigue
Improved production efficiency
Enhanced cutting consistency
8. Accurate Manual Sawhead Lift System
The hand-crank sawhead lift provides precise thickness control.
Features:
Indexed locking positions
Consistent board thickness
Easy adjustments
Repeatable cutting accuracy
9. Durable Steel Rail Frame Construction
Built with rigid steel box tubing rails for long-term durability.
Advantages:
Excellent structural rigidity
Accurate log alignment
Long service life
Stable sawing platform
10. Advanced Log Handling Components
The LT15 includes practical log management features.
Standard Equipment:
Adjustable backstops
Quick-set screw log clamps
Secure log positioning
Improved cutting efficiency
Standard models cut logs up to 27.5 inches, while the WIDE version handles up to 35 inches.
The machine uses a 158" × 1.25" × 0.042" bandsaw blade.
Yes. It is available as both stationary and trailer-mounted configurations.
Yes. Modular extensions allow virtually unlimited expansion.
Gasoline engines from 14 HP to 25 HP and electric motors from 5.5 kW to 11 kW.
Up to 34 inches on LT15 CLASSIC WIDE models.
The standard LT15 uses manual log handling systems.
Yes. A 12V power feed option is available.
Forestry, farming, custom sawing, woodworking, and small commercial sawmills.
Its reliability, modular design, efficient thin-kerf cutting, and affordable ownership costs make it one of the most widely used portable sawmills available.
| Blade Length inches | 158" |
| Min/Max Blade Width | 1.25" to 1.25" |
| Machine Type | Sawmill |
| Blade Dimensions | 158" × 1.25" × 0.042" |
| Maximum Log Diameter (Standard) | 27.5" (70 cm) |
| Maximum Log Diameter (Wide) | 35" (90 cm) |
| Maximum Width of Cut (Standard) | 25.2" (64 cm) |
| Maximum Width of Cut (Wide) | 34" (86 cm) |
| Maximum Board Thickness | 10.5" (27 cm) |
| Maximum Log Length | 17' 8" (5.4 m) |
| Blade Wheels | 19" (483 mm) Steel Wheels |
| Optional Feed System | 12V Power Feed |
| Engine Options | 14 HP, 19 HP, 25 HP Gas |
| Electric Options | 5.5 kW, 7.5 kW, 11 kW |
| Max Log Diameter | 32" |
| Max Cut Width | 30" |
| Engine Options | 10 HP / 17 HP Diesel |
