20", 2HP Vertical Metalworking Bandsaw

Trajan VBS-2012

Standard Features

  • Blade Guide: Carbide
  • Blade Length: 156.5"
  • Blade Speed: Variable 65-3280
  • Coolant Pump: N/A
  • Cut Method: Vertical
  • Feed System: N/A
  • Miter Cut: No
  • Motor: 2HP 3Ø
  • Swivel Method: N/A
  • Table Height: 39.5"
  • Voltage: 230/460V
  • Ship Wt: 1310 lbs.

Cutting Capacity

Cutting Angle Stock Shape Stock Size
Rectangular Stock 12" x 20"
Square Stock 12" x 12"
Mouseover to zoom
Trajan VBS-2012 20-Inch 2 Horsepower Vertical Metalworking Bandsaw, 230/460-Volt 3 PhaseImage unavailableImage unavailableImage unavailableImage unavailable

Residential    Commercial
No    Yes
This item requires a fork-lift for delivery.

Trajan VBS-2012 Description and Features

20", 2HP Vertical Metalworking Bandsaw, 230/460-Volt 3 Phase

Built for heavy-duty production use, the Trajan VBS-2012 is designed for multiple uses, used for metal cutting as well as wood working. The variable speed drive combined with a two-speed gearbox provide a wide range of blade speed settings that can easily be read on the digital blade speed readout (standard equipment). The blade guard adjusts easily by means of hand wheel and lock. A Multi-tilting worktable makes it possible to cut at almost any angle. Standard equipment includes: blade welder, grinder, and cutter; worklamp, chip blower, and a blade and tire cleaning brush.

Table Tilt
Front & Back      8 Deg
Right 15 Deg
Left 12 Deg
• 2HP, 3Ph, 230/460V motor (Prewired 230V)
• Two-speed gearbox
• Blade guard adjusts quickly with hand wheel and lock
• Variable speeds provide proper adjustments for high efficiency cutting
• Multi-tilting worktable
