Trajan 170 Portable Band Saw

Trajan 170

Standard Features

  • Blade Guide: Roller
  • Blade Length: 80.1
  • Blade Speed: 30-80 MPM
  • Coolant Pump: N/A
  • Cut Method: Horizontal
  • Feed System: Manual
  • Laser Alignment: No
  • Miter Cut: Single 60°
  • Motor: 1650W
  • Swivel Method: Head
  • Table Height: 0
  • Voltage: 110V
  • Ship Wt: 150 lbs.

Cutting Capacity

Cutting Angle Stock Shape Stock Size
Bar Stock 6.6"
Rectangular Stock 6.6" x 6.6"
45° Bar Stock 4.9"
Rectangular Stock 4.9" x 4.9"
60° Bar Stock 2.9"
Rectangular Stock 2.9" x 2.7"
Mouseover to zoom
Trajan 170 High Performance Fabrication SawImage unavailableImage unavailableImage unavailableImage unavailable
Downloads
Item on backorder
$1,499.00

Temporarily Out Of Stock.
Residential    Commercial
No    Yes
This item requires a fork-lift for delivery.
FREE GROUND SHIPPING (*lower 48 only)

Trajan 170 Description and Features

Trajan 170 Variable Speed Portable Band Saw

Application

  • Cutting all types of steel up 6”.
  • Great for industrial fabricating, automotive, home shop and farm
  • Operators can go mobile without compromising precise cutting capabilities

Features

  • Industrial 110v single phase motor with variable blade speed controls
  • Cuts miters with head swivel, no need to reposition material when cutting angles
  • Large 0-60 degree miter scale allows you to cut accurate miters quickly and easily
  • Variable Speed motor allows you to cut variety of applications, from angle iron to stainless steel
  • Cuts without coolant and uses a standard blade length
  • Cast iron base to give increase rigidity of machine.

Benefits

  • Easy to carry to and from the work-site.
  • Quick and easy miter cutting producing straight and accurate cuts
  • This saw offers powerful sawing capability in a small lightweight machine
  • Easy and clean to use and offers long blade life

Blade Size: 6’ 8” X .035” X 3/4”

The Trajan 170 band saw is a robust portable cutting machine. We specifically engineered the 170 to make precise cuts without requiring a massive base. It’s ideal for when operators need to take a saw to an on-site job. A lightweight build means this band saw is easy to carry from location to location. Despite it’s small size, the Trajan 170 band saw has a powerful motor.

Ease of Operation

This cutting machine features a simplified blade tension and doesn’t need any coolant lubrication to function. It’s quick to set up and easy to use in many situations. The Trajan 170 can be calibrated to the exact cutting angle that the operator requires — anywhere between 0 and 60 degrees. It also has an electronic blade speed regulator. An arch-blocking device makes the Trajan 170 simple to handle and maneuver.

Trajan Reliability

Trajan saws are designed by experts in the metal sawing industry. We’re familiar with the variety of obstacles that operators need to overcome throughout their work day. Jobs can take you to a whole range of locations and the Trajan 170 can come with you.

Powerful Variable Speed Portable Band Saw

  • Adjustable left cutting angle from 0 to 60 degrees
  • Powerful 110v single phase motor with electronic blade speed regulator
  • Anti-reset safety function
  • Cut without lubrication
  • Designed arch-blocking device for easy handling
  • With standard blade and length stop set
  • Simplified blade tension
  • Easy to carry
